EXT-HBT70-SET

The EXT-HBT70-SET is an HDBaseT Extender set consist of trans-mitter (EXT-HBT70-T) and receiver (EXT-HBT70-R). The extender set consists of a transmitter and receiver pair. HDMI signals are input into the transmitter and HDBaseT technology is used to transmit the signals to the receiver up to 70 m via a Cat5e/Cat6 cable. The receiver then outputs the HDMI signal. Bi-directional IR is also transmitted across the Cat5e/Cat6 cable. The extender set supports PoC, which can be used to power the receiv-er via the Cat5e/Cat6 cable. This eliminates the need for power at the receiver end.

Features:

  • Supports 4Kx2K@60Hz up to 40 meter and 1080p up to 70 meter
  • HDMI 1.4 & HDCP 2.2.
  • compliant, Bi directional IR and Power over Cat

Data sheet EXT-HBT70-SET

User Manual EXT-HBT-70-SET

EXT-UHBT70-SET

EXT-HBT100-SET

The EXT-HBT100-SET is an ultra-thin HDBaseT Extender set consist of transmitter (EXT-HBT100-T) and receiver (EXT-UHBT100-R). It distributes HDMI signal via CAT5e/CAT6a cable at 100meter/PoE for 1080p and 70 meter 4Kx2K and enables IR and RS232 passthrough to control remote displays. It also supports Ethernet interfaces for network. It provides a per-fect long range transmission solution at a 10.2Gbps bandwith. With an ultra thin design and PoE the EXT-HBT100-R receiver is an ideal solution to easily mount behind a display without need of power. Transmitter or receiver can be bought seperately.

Datasheet EXT-HBT100-SET

Manual EXT-HBT100-SET











EXT-HBT100-SET
